Mobiflight Seat Belt & No Smoking Sign Panel

Mobiflight Seat Belt & No Smoking Sign Panel You need: - Compatible Arduino board (Mega, Micro, Uno, ...) - 2x warm white or wold white LED's with matching resistor (I used two warm white 3mm LED's with a 1kΩ resistor) - 2x M3x8mm countersunk screws (all M3 countersunk up to 10mm should work fine) - Jumper cables - Overhead projector foil (There are laser and inkjet overhead projector foils, it depends on what printer you have) Due to copyright reasons I won't be able to provide the image for printing, since I took one from the Internet. Just google "airplane seatbelt sign" and print it on overhead projector foil. You can also cut the seat belt and non smoking sign with a plotter on a black foil and stick it on a piece of transparent foil. The dimensions of that final piece of foil should be 115 x 30 mm. Use some tape to stick it to the back of the frame. I won't explain in detail how to set this up in Mobiflight, because there are many good videos about Mobiflight on YouTube already. 1. Build and assemble the panel as shown in the pictures 2. Connect (+) of the no-smoking LED to Pin 2 (or whatever pin you like) of your Arduino 3. Connect (+) of the seat belt LED to Pin 3 (or whatever pin you like) of your Arduino 4. Connect (-) of both LED's to the Arduino's GND (don't forget resistors) 5. Watch the video on how to set it up in Mobiflight: Enjoy the build! Disclaimer: Always check your Arduino circuits for short circuits, as these can damage your Arduino board or computer! This is my own creation, do not re-upload without my permission.
